Product Features
| Item | Specification | Item | Specification |
| Print Size (W*D*H): | 245*245*240 mm | Auxiliary Part Cooling Fan: | ✔ |
| Printer Dimensions: | 477*467*489 mm | Chamber Circulation Fan: | ✔ |
| Package Dimensions: | 545*535*595mm | Chamber Temperature: | 60° C Independent Chamber Heating |
| Cross Weight: | 20.3kg | Recommended Filament: | PLA, ABS, ASA, PETG |
| Net Wetiht: | 17kg | Compatible Filament: | TPU,PA, PC, Carbon/ Glass Fiber Reinforced Polymer |
| XY Structure: | CoreXY | Dry box: | Optional |
| X/Y Axis: | 10mm/8mm High hardness linear hollow steel shafts belt tensioned automatically | Filament Tangle Detection: | ✔ |
| Z Axis: | Dual Independent Lead Screw Motors | Filament Run Out Sensor: | ✔ |
| Print Head Temperature: | ≤ 350℃ | Automatic Leveling: | Hands-free Automatic Leveling |
| Extruder: | Direct Extruder Hardened Steel Gears | Input Shaping: | ✔ |
| Hot End: | Ceramic Plate Heating Hot End | Power Loss Recovery: | ✔ |
| Nozzle: | Bimetal Nozzle | Voltage: | 100-240 VAC, 50/60Hz |
| Nozzle Diameter: | 0.4mm （0.2/0.6/0.8mm Optional） | Rated Power: | 350W+300W(Chamber Heater) |
| Filament Diameter: | 1.75mm | Display Screen: | 4.3 Inch 272*480 Touch Screen |
| Printing Platform: | Aluminum Substrate Heating Bed | Storage: | 32G EMMC and USB2.0 Flash Drive |
| Printing Plate: | Dual-Sided Textured PEI Plate | Camera: | Low Framerate Camera (Up to 1080P) Timelapse Supported |
| Hot Bed Temperature: | ≤ 120℃ | Wifi Module: | 150M 2.4G |
| Max Speed of Tool Head: | 600mm/s | Slicer: | QIDI Slicer and other third-party software, such as PrusaSlicer, Orca etc. |
| Acceleration: | ≤20000mm/s^2 | File Formats for Slicing: | STL, OBJ, 3MF,STEP,STP |
| Operating System: | Windows、MacOS、Linux | Q1 Pro TDS: Download | |
